F-G100
- Edge Computing Gateway
- Outer shell: metal, IP30 waterproof and dust-proof protection
- Standard ports: RS232, RS485, Ethernet, Wi-Fi
- CPU: industrial 32-bit processor & wireless module
- System: watchdog design, complete mechanisms, stable operation
- Other specifications: the F-G100 gateway supports remote management, SYSLOG, SNMP, TELNET, HTTPS, etc.
- OS Linux
- VPN GRE
- Support multiple WAN connection methods (static IP, DHCP, PPPOE, etc.)
- Support 3G/4G/5G and wired WAN dual link intelligent switch backup function (optional)
- Support VPN client (PPTP, L2TP, IPSEC)
- Support VPN sever (PPTP, L2TP, IPSEC)
- Support remote management, SYSLOG, SNMP, TELNET, SSHD, HTTPS
- Support local and remote online upgrade, import and export configuration files
- Support NTP, built-in RTC
- Support various of DDNS
- Support VLAN, MAC address clone
- Support WIFI AP mode, client mode, bridge mode (Optional)
- WIFI supports 802.11b/g/n/ac, support WIFI AP, AP Client, and other working modes (Optional)
- WIFI supports multiple encryption methods (WEP, WPA, WPA2, MAC address filtering)
- Support APN/VPDN
- Support multiple DHCP server and DHCP client
- Support DHCP binding MAC address/DDNS/NAT/DMZ/QOS, traffic statistics, etc.
- Support TCP/IP/UDP/FTP/HTTP and other network protocols
- Connect to the Four-Faith cloud platform to achieve remote management
- Support PC Client software to achieve remote configuration, data monitoring, and other features
- Can access to the Ali could, Huawei Could and other third-party could platforms
- With Python, C secondary development, applications can be customized
- Built-in various communication protocols (Modbus RTU/Modbus TCP/IEC60870_5_104, and etc.)
- Supports encryption modes such as DES and 3DES, and supports VRRP hot backup
- Local storage supports flash memory, TF card (or built-in eMMC)
- Provide secondary development kit (SDK), easy to use various system interfaces and resources
- Use MQTT+SSL/TLS Https WebSocket to connect to the IoT platform
Four-Faith Industrial Intelligent Gateway F-G100
- The F-G100 is a wireless intelligent gateway launched by Four-Faith for industrial IoT, and it can provide safe, reliable, and continuous access to the Internet for users through 4G, 5G wireless networks and broadband services.
- The F-G100 gateway adopts industrial-grade designs, including an industrial 32-bit processor and wireless module, and with standard IoT ports including RS232, RS485, and Ethernet LAN, the F-G100 has the capacity to connect multiple devices simultaneously for data transmission.
- The F-G100 has been widely used in M2M fields of the IoT industry, including smart factories, smart cities, smart grids, etc.
Wireless Specification
| Project | Content |
| Module | Industrial wireless module |
| Standard | 5G NR: n1/n2/n3/n5/n7/n8/n20/n28/n41/n66/n71/n77/n78/n79 LTE:B1/B2/B3/B4(66)/B5(18/19/26)/B7/B8/B12(17)/B13/B14/B20/B25/B26/B28/ B29/B30/B38/B39/B40/B41/B42/B43/ B46/ B48/B71 |
| Theoretical bandwidth | 5G NR：DL 3.4Gbps，UL 350Mbps LTE Cat20：DL 2.0Gbps，UL 150Mbps HSPA+：DL 42Mpbs，UL 5.76Mbps |
| Transmit power | <23dBm |
| Receiving sensitivity | <-97dBm |
WIFI Specification
| Project | Content |
| Standard and Frequency | Support IEEE802.11b/g/n，2.4G, 2*2 MIMO，AP mode，Station mode（optional） Support IEEE802.11ac，5.8G, 2*2 MIMO，AP mode，Station mode（optional） |
| Theoretical bandwidth | IEEE802.11b/g：Max Speed 108Mbps IEEE802.11n：Max Speed 300Mbps IEEE802.11ac：Max Speed 780Mbps |
| Security | Support WEP、WPA、WPA2，WPS Optional |
| Transmit power | 26dBm（11b），21.5dBm（11g），20dBm（11n），16dBm（11ac） |
| Receiving sensitivity | <-72dBm@54Mpbs |
Hardware System
| Project | Content |
| CPU | Industrial 32-bit communication processor |
| FLASH | 32MB |
| DDR3 | 512MB |
| TF | 8GB/32GB，optional |
Interface
| Project | Content |
| WAN Interface | 1 * 10/100/1000M Ethernet（RJ45），Adaptive MDI/MDIX，Built-in 1.5KV ESD Protection |
| LAN Interface | 4 * 10/100/1000M Ethernet（RJ45），Adaptive MDI/MDIX，Built-in 1.5KV ESD Protection |
| Serial | 1 * RS232，5 * RS485（One shared with RS232 interface），Built-in 1.5KV ESD Protection，The serial port parameters are as follows: Data bits: 5, 6, 7, 8 Stop bits: 1, 1.5 (optional), 2 bits Check: no check, even check, odd check, SPACE (optional) and MARK check (optional) Serial port speed: 2400 ~ 115200bits / s |
| Indicators | "PWR", "SYS", "WIFI", "SIM", "Online","Signal Strength" |
| I/O Interface | 6-pin 3.5mm terminal block; 2 DI, 1 DO, 1 relay Input high level: 5 to 30 VDC Input low level: 0 to 3 VDC Load current <50mA @ 30VDC Relay load: 1A 250VAC / 30VDC |
| Antenna | Cellular: 2 standard SMA female antenna interfaces, characteristic impedance 50 ohms WIFI: 2 standard SMA male antenna interfaces, characteristic impedance 50 ohms |
| SIM/UIM | Standard drawer-type user card interface, support 1.8V / 3V SIM / UIM card, built-in 15KV ESD protection |
| Power | 2-pin terminal power socket with built-in reverse power protection |
| USB | Standard USB3.0 interface, support various USB storage |
| TF card | Standard bullet TF card interface, support various TF cards |
| Reset Button | Through this button, the parameter configuration of the smart gateway can be restored to the factory value. |
Power Supply
| Project | Content |
| Standard | DC 12V/1.5A |
| Range | DC 9~36V |
| Working current | <1.2 A(12 VDC) |
| Standby current | <800mA(12 VDC) |
Physical properties
| Project | Content |
| shell | Metal case, protection class IP30 |
| Size | 172x122x38 mm (Excluding antennas and mounts) |
| Weight | 700g |
Others
| Project | Content |
| Operating temperature | -35~+75ºC（-31~+167℉） |
| Storage temperature | -40~+85ºC（-40~+185℉） |
| Relative humidity | 95%(No condensation) |
Order Info
| Model | Content |
| F-G100-NR | Cellular (5G NR), WIFI, SIM*1, I/O(2*DI, 1*DO, 1*Relay.) |
